The SDA10-48100-3U series uses new LiFePO4 technology. The product is safe, durable and easy to install.
Please download full specifications sheet here.
Key Advantages
- High energy density (more energy with less weight and footprint).
- High charge currents (short charge period).
- High continual power available.
- Long battery life (up to three times the battery life of a conventional battery).
- High efficiency between charging and discharging.
- Model: 16S.
- Parallel communication: Maximum support for 16 sets in parallel.
- 10 year warranty
Technical Specifications
- Nominal Voltage: 51.2V.
- Rated Capacity: 100Ah (C5, 0.2C to 40V at 25C).
- Operating voltage range: 42V-56.4V.
- Boost/Float Charge Voltage: 57.6/54V
- Charging Current (Current Limiting): 10A.
- Discharge Current (Maximum): 100A.
- Discharge Cut-Off Voltage: 40V.
- Dimensions: 442 mm±2mm*177mm±2mm*400 mm±2mm.
- Weight: 45.0kg±1.0kg.
