wall-mounted lithium battery typically refers to a lithium battery system that is designed to be mounted on a wall. These systems are commonly used for energy storage applications, such as in residential or commercial settings with solar panels or as backup power sources.
Features
Overvoltage protection
undervoltage protection
short-circuit protection
low-temperature charge protection
High-temperature charge protection
Low-temperature discharge protection
High-temperature discharge protection
Charge over-current protection
Discharge over-current protection
Dormancy function
RS485 communication
CAN communication
RS232 communication
Specifications
Rated Voltage: 51.2V
Nominal capacity: 96.6Ah, 4.95kWh
Height: 512 x 442 x 222.6 mm
Weight: 51 kg
Charge mode: CC/CV/CP
Max.Charge Current: 80A
Charging cut-off voltage: 57.4V
Discharge mode: CC/CP
Discharging cut-of-voltage: 44.8V
Max.Discharge Current: 150A
Peak Discharge Current: 350A(100ms)
Humidity: 5% to 95% Relative Humidity (Non-condensing)
Operating Temperature: Charge：0~+50℃/Discharge：-20~+55℃
Storage Temperature: -20~+45℃（three months）/-20~+25℃（one year）
Shipment status: Voltage：52V~54V SOC：60%~80%
Compatibility (Tested with many inverters)
Sunsynk
Deye
Growatt
Voltronic
Kodak
