Frecon 0.55kW 3PH 220V Pump VSD PV Starter Kit

Frecon 0.55kW 3PH 220V Pump VSD PV Starter Kit

Frecon 0.55kW 3PH 220V Pump VSD PV Starter Kit

Frecon 0.55kW 3PH 220V Pump VSD PV Starter Kit

Frecon 0.55kW 3PH 220V Pump VSD PV Starter Kit

Regular price R 10,000.00

Wishlist Compare

Guarantee safe checkout

Frecon 0.55kW 3PH 220V Pump VSD PV Starter Kit

R 10,000.00

Technical Specifications

Product Code: M1-PV-0.55-220V.
Adaptive Motor kW: 0.55.
Max Motor Rating: 4.2A.
Dimensions (HxWxD): 450mm x 300mm x 220mm.
Recommended Solar Panels: 5 X 280W (65V) Panels.

Input specification

PV Input
Maximum Input DC: Voltage 400VDC.
Recommended Voc Range: 320 - 370VDC.
Recommended MPPT Voltage Range: 250 - 350VDC.
Starting Voltage Range: 80 - 450VDC.

Grid or backup generator input

Input voltage: Single phase 220V (-15% to 30%).

Output specification

Rated output voltage: 3PH 220V.
Output frequency: 0 - 600.00Hz（default: 0～50.00Hz）.

Protection
