Inverter compatibility:
- TBB
- Growatt
- LuxPower
- Megarevo
- SofarSolar
- Deye
- MUST
- Victron
- Voltronic
- SAJ
When making your purchase , please advise on your inverter brand so that our technical team can program this product for your specific inverter unit
Features:
- LiFePO4 Cell
- Isolated Design
- High safety performance
- Modular design
- Easy Installation,
- One-touch on/off operating control
- High quality battery management system
- High reliability performance
- LED smart display - 4 lights show the state of capacity , 2 lights show the battery status
- Multiple communication interfaces - RS232 , RS485 . CAN
- Parallel - up to 16 units
- Extremely low power consumption in multiple modes of operation, standby and sleep.
- Use of environmentally friendly process technologies , RoHS compliance
- Warranty: 5 years
Basic Parameters
- Rated energy: V
- Minimum energy: 5000Wh
- Rated voltage: 51.2Vdc
- Battery capacity (Ah) : 100
- Dimension (WxHxD): 649×474.7×181.5mm
- IP grade: IP20
- Heat dissipation mode: Natural cooling
- Weight: ≈60kg
Electric Parameters
- Working voltage: 44-57.6Vdc
- Charging method: CC-CV
- Recommended charge current: 50A
- Maximum charge current: 100 A
- Recommended discharge current: 50A
- Maximum discharge current: 100A
- Maximum discharge power@25°C: 5000W
Performance Parameter
- Charge temperature/Humidity range: 0°C~45°C / 45%~85%
- Discharge temperature/Humidity range: -10°C ~50°C / 45%~85%
- Storage temperature/Humidity range: -20°C ~60°C/ 5%~85%
- Design cycle life: over 5000 cycles(Under certain test conditions)
- Maximum number of parallel machines: 16
- Certificate: CE, UN38.3
