Our Low Pressure Water Heating Solution offers an efficient and eco-conscious way to heat water for residential or commercial use. With advanced heat pump technology and thoughtful design, this unit delivers reliable performance while reducing energy costs.
- Primary heating by heat pump reduces overall energy consumption
- Proprietary Coil Heat Exchanger prevents limescale build-up
- Integrated connection points for optional solar panel integration
- Wi-Fi connectivity for remote monitoring and adjustments
- 2kW traditional heating element available for boosting performance during peak demand or in case of heat pump failure
Technical Information
- Model: EMS THERMAL EMS-TH200DT
- Heating Method: Heat Pump & Element
- Rated Input Power: 0.765 kW
- Rated Heating Capacity: 3 kW
- Rated Current: 3.5 A
- Power Supply: 220 - 240V / 50Hz
- Auxiliary Heater: 2kW Element
- Refrigerant: R-410A
- Water Tank Empty Volume: 220 L
- Water Tank Material: Fibreglass
- Water Inlet/Outlet Connection: 3/4” BSP
- Insulation Thickness: 50 mm
- Water Heating Coil Pressure Rating: 1000 kPa / 10 Bar / 145 psi
- Tank Pressure: Atmospheric
- Water Heating Coil Material: 304 Grade Stainless Steel
- Condenser Coil Material: 316 Grade Stainless Steel
- Max Water Output Temperature: 60°C
- Solar Compatible: Yes (Coming Soon)
- Air Duct Size: 180 mm
- Fan Motor Type: ø190 x 80
- Fan Power Input: 25 W
- Evaporator Size: 400 mm x 355.6 mm x 44 mm
- Height of Water Inlet & Outlet: 1335 mm
- Overall Dimensions (L x B x H): 798 mm x 659 mm x 1781 mm
- Unit Weight: 92 kg
