FEATURES
- 100% OFF GRID Solution
- NO Batteries or AC Required
- NO Timers required
- Variable Speed DC Motor
- MPPT Controller
- Pool water to be turned twice in 24 Hours
- 17.0m³ x 5.5Hrs p/day = (93.5m³/2) = 46,750 Ltrs
- 50mm Inlet / 50mm Outlet
| Model |
JP17-15-500 |
| Litres Per Minute |
L |
| Max. flow rate (m³/h) |
17.0 |
| Max. flow rate (Litres/h) |
17,000 |
| Max. Pool Size |
46,750 Litres |
| Max. Head (m) |
15 |
| Ambient Temp |
-30 to +45 |
| Input voltage |
48v DC |
| Type of enclosure |
IP54 |
| Max. power input (W) |
500 |
| Class of insulation |
F |
| Suction Inlet Lift |
3.0 m |
| Max. casing pressure |
2.5 bar |
| Max. water temp |
+60 °C |
| Controller Input |
48V - 100V (VoC) |
| Impeller |
SOLAR PANEL RECOMMENDATIONS
| PANELS |
VOLTAGE (VMP) |
QTY |
| 545 Watts |
49.4 V |
2 |
PACKED DIMENSIONS
| Length |
520 mm |
| Width |
220 mm |
| Height |
350 mm |
| Weight |
17 kgs |
What is included:
- 1 x Bundu Power 2 Way Pump Box
PLEASE NOTE: Submersible Cabler (6mm 3 Core) sold separately.
KEY ASSUMPTIONS
- Your pool water should be turned twice in a 24 hour period
- This pump will drive most pool cleaners
- Max pool size: (Flow Rate * 6Hrs per day) / 2 = Pool Size
- Higher head = less suction for pool cleaner
- Pump will start from sun-up to sun-down daily
How to determine Pool size
- Width (m) x Length (m) x Average Depth (m) x 1000 = Litres
- I.e.: 5m x 3m x 1.2m = 19.2m x 1000 = 19 200 Litres
- Pump size determined by rotating water twice in a 24 Hour period. Calculated on
- 6 hours at maximum pumping capacity per day.
- This pump is a replacement for your existing pool pump and it will work with your pool cleaner. It does not heat water.
PLEASE NOTE: Exceeding the recommended Input Voltage () to the controller can damage the controller and void your warranty. Please ensure the correct panel configuration before connecting the pump controller.
